Descriere
CHASSIS:
INSTALLED DEVICES / MODULES QTY: 2
SUPPORTED DEVICES / MODULES QTY: 24
SUPPORTED DRIVES: SAS-2
STORAGE:
TOTAL ARRAY CAPACITY: 600 GB
MAX SUPPORTED CAPACITY: 14.4 TB
HDD ARRAY EXTERNAL INTERFACE: SAS 6GB/S
STORAGE CONTROLLER:
TYPE: RAID
INTERFACE TYPE: SAS 6GB/S
DATA TRANSFER RATE: 600 MBPS
RAID LEVEL: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
HARD DRIVE:
TYPE: HDD - HOT-SWAP
CAPACITY: 2 X 600 GB
INTERFACE TYPE: SAS 6GB/S
SPINDLE SPEED: 10000 RPM
EXPANSION / CONNECTIVITY:
EXPANSION BAYS: 24 (TOTAL) / 22 (FREE) - 2.5 - HOT-SWAP
INTERFACES 2 X SAS 6GB/S - 26 PIN 4X SHIELDED MINI MULTILANE SAS (SFF-8088) ¦ 1 X SERIAL ( MANAGEMENT ) - 6 PIN MINI-DIN (PS/2 STYLE)
POWER:
POWER DEVICE: 2 X INTERNAL POWER SUPPLY - HOT-PLUG
MAX SUPPORTED QTY: 2
POWER REDUNDANCY: YES
POWER REDUNDANCY SCHEME: 1+1
VOLTAGE REQUIRED: AC 120/230 V - 50/60 HZ
POWER PROVIDED: 600 WATT
