Descriere
INSTALLED DEVICES / MODULES QTY: 0
SUPPORTED DEVICES / MODULES QTY: 24
SUPPORTED DRIVES: SERIAL ATA-300 / SAS
STORAGE:
MAX SUPPORTED CAPACITY: 16 TB
HDD ARRAY EXTERNAL INTERFACE: 4GB FIBRE CHANNEL
MAXIMUM LUNS: 512
STORAGE CONTROLLER:
TYPE: 2 X RAID ( 4GB FIBRE CHANNEL )
CONTROLLER INTERFACE TYPE: SERIAL ATA-300 / SAS
DATA TRANSFER RATE: 300 MBPS
CACHE / BUFFER SIZE ( MAX ): 1 GB
SUPPORTED DEVICES: DISK ARRAY (RAID)
RAID LEVEL: RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10, RAID 50
STORAGE HARD DRIVE:
INTERFACE TYPE: SERIAL ATA-300 / SAS
EXPANSION / CONNECTIVITY:
EXPANSION BAYS TOTAL (FREE): 24 ( 24 - 2.5
INTERFACES:
2 X SERIAL RS-232 - 9 PIN D-SUB (DB-9)
2 X MANAGEMENT - RJ-45
4 X 4GB FIBRE CHANNEL
2 X SERIAL ATTACHED SCSI
POWER:
POWER DEVICE: POWER SUPPLY - HOT-PLUG - PLUG-IN MODULE
POWER REDUNDANCY: YES
POWER REDUNDANCY SCHEME: 1+1
