Descriere
CABINET (CHASSIS):
INSTALLED DEVICES / MODULES QTY : 0
SUPPORTED DEVICES / MODULES QTY : 24
SUPPORTED DRIVES : SERIAL ATTACHED SCSI 2
STORAGE:
MAX SUPPORTED CAPACITY : 12 TB
HDD ARRAY EXTERNAL INTERFACE : SERIAL ATTACHED SCSI 2
STORAGE CONTROLLER:
TYPE : RAID
CACHE / BUFFER SIZE ( MAX ) : 1 GB
SUPPORTED DEVICES : DISK ARRAY (RAID)
RAID LEVEL : RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10
HARD DRIVE:
TYPE : HOT-SWAP - PLUG-IN MODULE
CAPACITY : 0
EXPANSION / CONNECTIVITY:
EXPANSION BAYS TOTAL (FREE) : 24 ( 24 ) X HOT-SWAP - 2.5 SFF
INTERFACES : 2 X SERIAL ATTACHED SCSI 2 ( INPUT ) - 26 PIN 4X SHIELDED MINI MULTILANE SAS (SFF-8088) 1 X SERIAL ATTACHED SCSI 2 ( OUTPUT ) - 26 PIN 4X SHIELDED MINI MULTILANE SAS (SFF-8088) 2 X ETHERNET ( MANAGEMENT )
POWER:
POWER DEVICE : 2 X POWER SUPPLY - HOT-PLUG - PLUG-IN MODULE
MAX SUPPORTED QTY : 2
POWER REDUNDANCY : YES
POWER REDUNDANCY SCHEME : 1+1
VOLTAGE REQUIRED : AC 120/230 V ( 50/60 HZ )
POWER PROVIDED : 585 WATT
